The Voltcraft VC-960 multimeter is a family member of the 900 Pro series. The VC-960 has 40,000 count displays and a basic accuracy of 0.025% (DC/V). The AC and DC coupled True RMS measurement combined with MSP measuring technology ensures accurate measurements of a wide range of input voltages. The VC-960 has a data logger for storing up to 10,000 measurement points. The device meets the safety category CAT III 1000V, CAT IV 600V.

An absolute highlight in this price range is the 400kHz bandwidth in the AC / V range. The instruments are fitted with an opto-electronic interface utilising fibre-optic technology thereby ensuring a safe galvanic isolation between instrument and PC. The instruments are ergonomically designed and provided with a sprayed-on soft rubber protection, thus removing the need for a separate holster. • The VC960 has all the functions of the VC-920 with an additional • Measurements in the range of overvoltage categories III (1000V) and IV (600V) • Measurement of DC voltage to max. 1000V DC • Measurement of AC voltage to max. 750V AC / AC+DC True RMS • Measurement of direct and alternating currents from 0A to 10A (AC / AC+DC True RMS) • Measurement of capacitance to 40mF • Measurement of frequencies to 400MHz • Display of duty cycle in% • Measurement of resistances to 40M½ • Continuity test (.

Project vc840/vc820 Software for the multimeters vc840/vc820 Software for reading the data from the cheap digital multimeter VC 820 (about 50 EUR in 2007) or VC 840 (=VC 820 + True RMS, about 85 EUR in 2007) from with posix commands via a serial port. They can be combined e. With the clamp-on ammeter VC 601 (about 69 EUR in 2007).

Tested with Linux, should work with every posix conforming operating system and. The software should also work with newer VC DMMs, e. The VC-830, VC-850, VC-870, VC-920, VC-940 and VC-960. Because the protocoll is compatible with the DT 9062 it should also work with this DMM and successors.

Crack Think3 2009 Audi. Feflow 6 2 Crack Rocks. Voltcraft Vc 960 Software Download Data from the VC- 9. DMM VC 960 USB 1 via Voltcraft 121598 1 1 1. Hardware supported by ABACOM software products.

For communication with the PC/Notebook/. Also a an USB adapter (with opto coupler) is availible, e. At conrad.de. For realtime plotting the data for printing the plot as a postscript and a png file is the source code Example output, with time in seconds since start, voltage and flags: 0.3 -9.300 mV () 0.7 -9.400 mV () 1.0 -9.500 mV () 1.4 -9.600 mV () 1.7 -9.600 mV () 2.1 -9.700 mV () 2.4 -9.700 mV () 2.8 -9.800 mV () 3.1 -9.900 mV () 3.5 -9.900 mV () 3.8 -10.000 mV () 4.2 -10.100 mV () 4.5 -10.200 mV () 4.9 -10.300 mV () The digital multimeter (DMM) can be powered from the USB bus, instead from battery, but the ground of the USB is not the ground (COM) of the DMM input. The ground of the DMM input has a negative voltage. The MS-Win program provided with the DMM, is very poor and produces binary data files like Ut70bdb.PX Ut70bdb.DB and you need special software to get the data in CSV format or read them with a program like MS-Excel. The DB file can be read from MS-Excel, but only with problems like no time.

Conrad offers the DMM PROFILAB SOFTWARE for around 36 EUR which should not have these problems. GNU-Software for the similar cheap MAS-345 or a Digitek-4000 multimeter, connected through an RS-232 port can be found here:. The multimeters of type Metex M-4650CR are also similar, also at 1200 Baud: With my first USB-RS232 (USB to Serial Adapter) adapter with an Pl2303 (driver pl2303) i've got the problem that this adapter does nothing after some hours and a user (Stephan R.) reported defect checksums and lost bytes with such an adapter while communication works without problems with an onboard serial port. I'm now using an USB to Serial Adapter with an FTDI chip (driver ftdi_sio, chip FT232BM) without problems. Clonezilla Software Raid 1 there. Update 2011-11 A newer DMM with one digit more, wider measurement ranges and more serial speed (9600 instead of 1200 Baud) is the, for about 47 Euro (including shipping) e.

But at some points it's not better: 10 instead of 20 A maximum and no temperature measurement. Sourcecode for reading the data, plotting with gnuplot etc. Can be found e.
